187 © STULZ GmbH – all rights reserved EN/06.2019/G57
C7000 INSTRUCTIONS fOR A/C UNITS
Hotgas bypass valve
Electronical expansion valve
Valves in the refrigerant circuit
Range HGBP valve 1 HGBP valve 2
Component configured 0 - 1 0 0
Output A 0 - 20 0 0
P-factor 0 - 100 20 20
I-factor 0 - 100 20 20
D-factor 0 - 100 20 20
Control cycle 1 - 10 s 2 s 2 s
Pre-open time 0 - 120 s 15 s 15 s
Pre-opening 0 - 100% 50% 50%
Minimum opening 0 - 100% 0% 0%
Maximum opening 0 - 100% 20% 100%
Range EEV 1 EEV 2
Component configured 0 - 1 0 0
Controller type 0 - 1 0 0
Valve type 1 - 5 2 2
Refrigerant 0 - 7 4 4
Pressure sensor 0 - 3 0 0
MOP temperature -40 - 40°C 0°C 0°C
Start opening 10 - 100% 50% 50%
Pre-open time 1 - 30 s 5 s 5 s
Alarm priority pressure sensor 0 - 31 0 0
Common alarm pressure sensor 0 - 1 0 0
Alarm priority temperature sensor 0 - 31 0 0
Common alarm temperature sensor 0 - 1 0 0
Alarm priority motor 0 - 31 0 0
Common alarm motor 0 - 1 0 0
Superheating SP normal 5 - 30°C 7°C 7°C
Superheating SP dehumidification 5 - 30°C 12°C 12°C
Range Suction valve 1 Suction valve 2
Start 0 - 9,9 K
0 K 0,4 K
Gradient 0,5 - 9,9 K
0,5 K 0,5 K
Minimum opening 0 - 100 %
20 20
Component configured 0 - 1
0 0
Output A 0 - 20
5 6
Suction valve
