2726
6. Wiring
With Brake. 3-phase motor. Plugging operation
Premium-eciency, 3-phase motor
ESB-250, ESB-250-2
8 lead wires
Direct on-line starting
‒Δ
starting
Quick braking circuit 200V class
Control Panel
At start
Wiring
MC
M
ON
MC
OFF
MC
ON
When acceleration
is completed
 wiring
MC
M
ON
MC
ON
MC
OFF
Control Panel
Motor
Motor
Quick braking circuit 400V class
Control Panel
At start
Wiring
MC
M
ON
MC
OFF
MC
ON
When acceleration
is completed
 wiring
MC
M
ON
MC
ON
MC
OFF
Control Panel
Motor
Motor
Electromagnetic contactor for normal and reverse rotation
MC: Electromagnetic contactor
OLR: Overload protection device or electronic thermal relay
Tr: Transformer capacity 250–600VA, secondary voltage 200–220V
F: Fuse 3–5A
Customer to prepare.
- This diagram shows cases for motors with standard Japanese domestic specications. Please consult with us for motors with
overseas specications.
- For brake types, see Table 1-6 on P7.
- Use with a quick braking circuit. For information on electromagnetic contactors for quick braking circuits, see Table 6-4 on P32.
- Rectiers are external to the main unit. Rectiers are made for indoor use. Install in an area where they will not come into contact
with water, etc.
- The brake unit is for 200V class. For 400V class power sources, prepare a 400V/200V transformer.
- For plugging operations, gang the brake circuits electromagnetic contactors to the motor’s normal and reverse rotation
electromagnetic contactors
U1 V1 W1
V2 W2 U2
1 23456
43
Rectier
Brake
MC
OLR
Motor
RS
T
U1 V1 W1
V2 W2 U2
1 23456
43
Rectier
Brake
MC
OLR
Tr
F
400V 200V
Motor
R
S
T
Normal rotation
Reverse rotation
MC
M
MC
Δ
MC
OLR
U1 V1 W1 V2 W2 U2
123456
43
Motor
Rectier
Brake
RS
T
Normal rotation
Reverse rotation
Tr
F
400V 200V
MC
M
MC
Δ
MC
OLR
U1 V1 W1 V2 W2 U2
123456
43
Motor
Rectier
Brake
MC
MC
RS
T
Normal rotation
Reverse rotation
Normal rotation
Reverse rotation
