S CLASS™ cutter User’s Manual
Setup 1-6
5. Tool carriage: The tool carriage is the mount for the knife holder, pen or pouncing
tool. It has also holds the Optical POSitioning sensor (OPOS) and a cut-off knife to
cut a sheet from the roll when a job is finished.
6. Cutting strip: A self-healing orange strip helps avoid any damage to the knife tip
when no media has been loaded. Since cutting is done on the cutting strip, it is
essential that the strip remains intact.
7. Pouncing strip: An extra black strip to pounce on.
8. Tool holder: The left end cap has a rim so it can be used for tool storage.
9. Screws to secure the cutter base: Make sure all three screws are secured at
each side before the cutter is used.
10. Media basket: The stand and linen media basket come standard with all S
CLASS™ cutters.
