Specifications 6-1
6 Specs and Genaral Information
6.1 Introduction
The S CLASS™ range of cutters has been designed to produce computer-generated
graphic designs on cut sheet or roll vinyl media. Using the integrated optical
positioning system (OPOS) allows contour cutting of printed sheets of material. By
replacing the knife with a pen, these cutters can also be used to produce inexpensive
previews of new graphic designs on paper.
The following cutter models are currently available:
• The S75, which can handle media widths from 60 mm up to 840 mm (2.4” to 33”)
and has a drag knife.
• The S120, which can handle media widths from 115 mm up to 1300 mm (4.5” to
51”) and has a drag knife.
• The S160, which can handle media widths from 170 mm up to 1680 mm (6.7” to
66”) and has a drag knife.
• The S75 T, which can handle media widths from 60 mm up to 840 mm (2.4” to 33”)
and has a tangential knife.
• The S120 T, which can handle media widths from 115 mm up to 1300 mm (4.5” to
51”) and has a tangential knife.
• The S160 T, which can handle media widths from 170 mm up to 1680 mm (6.7” to
66”) and has a tangential knife.
6.1.1 Product features
The following are the main features of the S CLASS™ cutters.
• Variable media widths.
• User-selectable DM/PL,
™
HP-GL,
™
and HP-GL/2
™
software languages.
• Interchangeable pouncing tool with its own pouncing strip.
• Integrated OPOS positioning and alignment system.
• Interchangeable pen for producing preview plots of sign designs on paper.
