S CLASS™ cutter User’s Manual
Detailed Operation 4-9
Emulation language:
The S CLASS™ cutters support DM-PL , HP-GL , HP-GL/2 and Auto.
DM-PL is the recommended plotting language and usually gives the best cutting
quality.
HP-GL emulates an HP 7585B, 7580B, 758X Series HPGL printer.
HP-GL emulates an HP Draftmaster RX / SX / MX 7595B type printer.
Press the button, then use
or to change the plotting language.
Press to confirm or to cancel.
The default setting is Auto.
HP-GL origin:
This option is not visible when the plotting language is set to DM-PL.
The origin can be set to Right Front or Center.
If the cut is found to be incomplete, and is located all the way in the upper left corner
of the media, then modify the HP-GL origin setting to Right Front.
If the cut is found to be incomplete, and is shifted to the lower right corner of the
media, then change the HP-GL origin setting to Center.
Press the button, then use
or to change the plotting origin.
Press
to confirm or to cancel.
The default origin setting is Right Front.
DM-PL addressing:
This option is only visible when the plotting language is set to DM-PL.
The user-addressable curve resolution can be set to 0.025 mm or 0.001" or 0.1 mm or
0.005".
Press the button, then use
or to set the resolution.
Press
to confirm or to cancel.
The default addressing resolution is 0.025 mm (Europe) or 0.001" (US).
USB class:
The USB class can be set to Standard, Printer Uni (unidirectional), or Printer Bidi
(bidirectional).
Standard mode is used for cutter drivers (either built into the design software or from a
bridge program like WinPlot).
Printer Uni and Printer Bidi are for use with printer adaptors with either network or
wireless connection.
Press the button, then use
or to change the USB Class.
Press
to confirm or to cancel.
The default USB class mode is Standard.
