S CLASS™ cutter User’s Manual
Specifications 6-4
6.2.3 Knife, pen and pouncing tool
The S CLASS™ cutter comes equipped with all the tools necessary to start working
immediately.
Some tools are pre-installed, while others are packaged in separate boxes.
Below is a table that specifies which tools were delivered with the cutter. Please make
sure that all tools were included with the cutter.
Medium
S75
S120
S160
S75T
S120T
S160T
Standard drag knife
Standard vinyl up to 0.25mm
(0.03”) thick
2 1
Sandblast drag knife (requires
sandblast knife holder)
Sandblast and materials thicker
than 0.25mm (0.03”)
x x
Standard tangential knife
Standard vinyl up to 0.25mm
(0.03”) thick
x
2
Sandblast tangential knife (requires
special sandblast nose piece)
Sandblast and materials thicker
than 0.25mm (0.03”)
x
1
Fiber type plotter type pen
Paper 1
x
Ball point pen (requires ballpoint
penholder)
Paper
x
1
Pouncing pin
Paper
1 1
Razor blade for cut sheet
Standard vinyl up to 0.25mm
(0.03”) thick
2 2
TABLE 6-3
6-3 S CLASS™ TOOLS
To order replacement knives, pens and/or pouncing tools, contact your local Summa
dealer, quoting the part numbers listed in table 6-8.
The S CLASS™ cutters will only perform according to specifications if a genuine
Summa knife, pen or pouncing tool is installed. Do not replace the standard knife, pen
or pouncing tool with products from other manufacturers.
