S CLASS™ cutter User’s Manual
Detailed Operation 4-12
4.3.2.5 Factory defaults
This option defaults all user parameters to factory default. The parameters that require
calibrating are not reset.
4.3.2.6 Confidence test
The confidence test performs a quick electrical and mechanical test of the cutter to
make sure that the cutter is fully operational. A media sheet of at least A3/B-size
should be used for this plot. This test is always cut at the left side of the loaded media.
4.3.2.7 Media sensor setup
The media sensor setup option is a useful routine for checking whether the front and
rear media sensors are functioning properly and whether the switching levels of these
sensors are correctly set.
11. Press
or to select the sensor that will be tested.
12. Put a piece of media half on the chosen sensor and under the two outer pinch
rollers. Press
.
13. There are five levels of sensitivity to choose from.
14. Use
or to change sensitivity level.
After choosing a sensitivity level, there will be a rectangle next to the sensitivity. When
the sensor is covered then the rectangle will be (completely) filled with black squares.
When the senor is uncovered, there will be (almost) no black squares in the rectangle.
Sensor uncovered Sensor covered
FIG 4-4
4-4 S SENSOR SETUP
The black stripe in the rectangle is the trigger level at which the cutter decides
whether there is media in the machine or not.
15. Use
and to change the trigger level if necessary.
Ideally there would be 2 to 4 black squares when the sensor is uncovered, the
rectangle is completely filled when it is covered, and the trigger level is set in the
middle
