S CLASS™ cutter User’s Manual
Setup 1-27
1.6.1.2 Pen installation
The S CLASS™ drag cutters can also be operated with a plotter-type pen. After
replacing the knife with a pen, the cutter can be used as a plotter to draw draft plots of
new or existing designs on paper.
1. Loosen the head clamp screw and swing the clamp arm back, then remove the
tool from the clamp.
2. Install the pen in the rear slot, close clamp arm, and tighten the clamp screw.
3. The change of tool can either be input on the touch panel with Summa Cutter
Control (PC only), or with the cutting software.
Selecting pen operation disables the knife offset correction, and changes the pressure
to “pen pressure.”
NOTE: The information on the touch panel shows the tool currently selected by the
cutter. Make sure the cutter’s tool setting matches the actual tool in use.
1.6.1.3 Pouncing pin installation
The S CLASS™ drag cutters can also be operated with a pouncing tool. After
replacing the knife with a pouncing tool, the cutter can be used as a paper pouncer.
1. Loosen the head clamp screw and swing the clamp arm back, then remove the
tool from the clamp.
2. Install the pouncing tool in the front slot, close clamp arm, and tighten the clamp
screw.
3. The change of tool can either be input on the touch panel with Summa Cutter
Control, or with the cutting software.
Selecting pouncing tool operation disables the knife offset correction, changes the
pressure to “pouncing pressure” and will add “pouncing gap” to the tool properties.
NOTE: The information on the touch panel shows the tool currently selected by the
cutter. Make sure the cutter’s tool setting matches the actual tool in use.
CAUTION: Before starting to pounce, check whether the pouncing tool is positioned
above the black pouncing strip. If the pouncing tool is mounted in the rear slot of the
clamp, the cutting strip will be irreversibly damaged.
