Summa S 75 - Cutter and Media Specifications

S CLASS™ cutter User’s Manual
Specifications 6-3
6.2 Specifications
6.2.1 Cutter
S75(T) S120(T) S160(T)
mm inch mm inch mm inch
Height
1110
43.7 1110 43.7 1110 43.7
Width
1410
55.5 1870 73.6 2250 88.6
Depth
folded basket
680
26.8 680 26.8 680 26.8
Depth
open basket
1080 42.5 1080 42.5 1080 42.5
Kg pounds Kg pounds Kg pounds
Weight 49.5 109 61.5 135.6 71 156.5
TABLE 6-1
6-1 S CLASS™ CUTTER SPECIFICATIONS
6.2.2 Media
S75(T) S120(T) S160(T)
mm inch mm inch mm inch
Width
60 to 840 2.4 to 33 115 to 1300 4.5 to 51 170 to 1680 6.7 to 66
Maximum
cutting width
(*)
742 29.2 1200 47.2 1580 62.2
Min margin
left/right
(**)
25 1 25 1 25 1
Front margin
45 45 45 45 45 45
Rear margin
Sensor on
Sensor off
45
33
1.75
1.3
45
33
1.75
1.3
45
33
1.75
1.3
Tracking
Performance
(***)
± 0.1mm up to 12 m (vinyl < 760mm)
± 0.004” up to 40 feet (vinyl < 30”)
± 0.1mm up to 4 m (vinyl >760mm)
± 0.004” up to 13 feet (vinyl >30”)
Media
Thickness
0.05mm to 0.25mm
0.002” to 0.01”
Up to 0.8mm (0.03” ) with sandblast drag knife
Up to 1.2mm (0.047” ) with sandblast tangential knife
(*)
Maximum cutting width in normal mode,’oversize mode’ allows a wider cutting area
(**)
For positioning of the pinch rollers (see section 1.5.1).
(***)
Media lengths greater than the specified length can be handled, but compliance with specifications is
not guaranteed (will be dependent on media type, media size and other parameters).
TABLE 6-2
6-2 S CLASS™ MEDIA SPECIFICATIONS
