S CLASS™ cutter User’s Manual
Setup 1-8
5. AC power cord receptacle: It is located at the left-hand side of the power entry
module. The power-up procedure is explained in detail in Section 1.3. Always use
a power cord that was delivered with your cutter.
6. USB port: This interface is based on the standards specified in Universal Serial
Bus Specifications Revision 1.1. It allows a high-speed bi-directional
communication between the host computer and the cutter.
7. RS-232 port: This DB-9P connector provides serial bi-directional communication
between the cutter and a host computer.
8. Screws to secure the cutter base: Screws (3 left and 3 right) hold the cutter
base to its stand. All the screws must be properly tightened before using the
cutter.
9. Tubes for media basket: Tubes in the back and front hold the media basket.
They can easily pulled outwards to put the basket in its place.
10. Casters: The casters on the stand are equipped with locking brakes. Once the
cutter has been moved to its new location, press the brakes with your foot to lock
the casters.
11. Media basket: The stand and linen media basket come as standard equipment
with all S CLASS™ cutters.
12. Roll media guide bushes: The two flange guides serve to keep the media roll in
place when media is pulled from the roll.
13. Media support rollers: Rotating support rollers for the media roll.
