S CLASS™ cutter User’s Manual
Setup 1-31
NOTE: The knife pressure can also be used to check the knife depth (which is
controlled by the amount the knife extends outs of the nosepiece). If the correct knife
pressure is raised by 150 gr, then the knife may not cut through the backing of the
vinyl. If it does, then the knife depth needs to be reduced.
CAUTION: After setting the cutting depth and/or the knife pressure, perform a
thorough visual check of the knife blade, which can be seen protruding from the knife
holder, and test cutting results on a scrap of vinyl media.
WARNING: Do not operate the cutter if the knife blade cuts through the media
backing, as this will seriously damage the cutter's rubber cutting strip and the knife.
CAUTION: For most vinyl cutting operations, the knife blade tip will be barely visible
at the bottom of the knife tool. If the knife blade tip is clearly visible, then the knife
depth must be readjusted.
To prevent damage to the cutter, check the depth of the knife blade tip and the quality
of the cut each time you load a different type of vinyl into the cutter.
