SUNWARD SWDE200B - Cab Electrical Controls

SWDE200B Operation & Maintenance Manual
21
2.3 ELECTRIC CONTROL SECTION OF CAB
FIG. 2.3.1 Electrical Layout in Cab
Bus Panel Rocker Switch
Fan Grease Filling Horn Rod Unloading/Upper Clamp Dust Hood/Lower Clamp Radio Air Conditioner Panel
Emergency Stop White Yellow Red Buzzer Ignition Key Accelerator Drilling Handle Extension/Levelling Boom Lift/Tilt Frame Lift/Tilt
Emergency Stop White Yellow Red Buzzer Ignition Key Accelerator Lock Mode Selection Air Supply
