9. MACHINE TECHNICAL SPECIFICATION
9.1 SWDE200B TECHNICAL PARAMETERS
SWDE200B
Operation parameters
Drilling Range mm
152
～
230
Impactor
5"/6"/8"
Drilling Diameter mm
114
Drill Rod Length m
6m×6
Max. Hole Depth m
36
Dust Collection Device
Dry Type
Air compressor
Manufacturer
Airman
Model
SK1050SH
Working pressure MPa
2.4
Displacement m
3
/min
31.3
Engine
Manufacturer
CUMMINS
Model
QSZ13-C550
Power kW/rpm
410/1900
Fuel Tank Capacity L
750
Feed
Feed Type
Motor-Chain
Length of Feed Beam mm
10550
Feed Stroke mm
6700
Feed extension mm
1300
Max. Feed rate m/s
0.8
Max. Feed force kN
40
Forward tilting angle °
140
Overturning angle °
-20
～
90
Boom
Full length mm
3200
Lifting angle °
50
～
-30
Oscillating angle °
L15 R45
Travel capability
Traveling speed km/h
3.2
Max. Traction force kN
125
Gradeability °
25
Track tilt angle °
±10
Ground clearance mm
480
Rotation
Rotation Speed rpm
95
Rotation Torque Nm
5650
