SWDE200B Operation & Maintenance Manual
2.4.4 Drilling Depth Detection Interface
Figure 3.6 Drilling Depth Detection Interface
Press “drilling depth detection”on main operating interface(figure 3.2)to enter“drilling
depth detection”. Click the corresponding button on the interface to perform corresponding
operation:
Press “RESET” (F8), the current depth will be reset. This button can be easily adjusted
when the working ground height of the rig is not the same. Place the drill bit on the ground and
press this button to set the current depth to zero depth.
2.4.5 Fault Code Interface
The alarm icon will flash when a fault or alarm signal occurs, you can click “Fault
Code” to enter monitoring interface to check the detailed alarm.
