SWDE200B Operation & Maintenance Manual
Icon 3“general parameters display” is the general parameters display area of the machine.
The host system voltage, air compressor system voltage, current drilling depth, the last drilling
depth, hydraulic oil temperature and water tank level will be shown.
Icon 4“air compressor parameters display” is the air compressor parameters display area
of the machine. The air compressor engine water temperature, air compressor exhaust
temperature and air compressor engine speed will be shown.
Icon 5“host parameters display” is the host parameters display area of the machine. The
host engine water temperature, fuel volume and air host engine speed will be shown.
The light blue state bar at the top is time and company name.
There F1 to F8 stand for the eight buttons at the left/right of the display. When the operator
presses a key, the system will enter into a corresponding interface.
Press “RETURN”（F1）to enter “instrument home page”，that’s the welcome screen.
Press “PARAMETER”（F2）to enter “parameter interface”(See figure 3.3)，to monitor
meters and sensors.
Press “SET” (F3), you will enter “setting interface” (See figure 3.4) to set the parameters.
Press “RESET” (F4), the current drilling depth will be clear, the display will be zero and the
drilling depth will be restarted.
Press “INCLINATION” (F5), you will enter “inclination interface” (See figure 3.5) to set
the inclination
Press “DRILLING DEPTH DETECTION”（F6）to enter “drilling depth detection interface”
(See figure 3.6)to set the drilling depth detection.
Press “FAULT CODE” (F7), you will enter “fault code interface” (See figure 3.7) to check
the record.
Press “IO PORT” (F8), you will enter “controller IO port interface” (See figure 3.8) to
check the controller IO pin data.
