7.0 SG-DRL5/DRL5E/DRL5-2L PSTN Line Cards

- 126 -

Setting Sescoa

Super Speed

4/2/checksum 4/2/checksum failed

double round kissoff

Decode Sescoa like

SG-DRL2A

00 disabled enabled enabled NO

01 enabled disabled disabled NO

02 enabled disabled disabled YES

03 disabled enabled disabled NO

For a list of detailed event messages for the SG-DRL2A/SG-DRL4 decoding of Sescoa format please reference the communication format document.

SG-DRL5 Option 1A6/2A6: ITI Adjust

Default (00)

When set to 01, the ITI account codes will be converted to 4 digits by stripping the last digit off. For example, a panel account of 23459 will become

account 2345. If the leading digit of the panel account is a 0 then it will be stripped and replaced with a space. For example, if 02349 is sent then the

receiver will output 234 for the panel account.

SG-DRL5 Options 1A8/2A8 - 1AF/2AF: Dial-out Number For 2-way Audio Transfer

Default (00)

These 8 options are used to provide the dial-out number if the user wishes to transfer the call to another extension. Up to 16 digits may be programmed

including any 'Feature Command' digits. The values in these options will be sent as DTMF tones on the phone line after the following sequence takes

place:

1. The receiver has recognized the current call as a 2-way audio

account and alarm code.

2. The calling control panel has finished sending its alarms and

switched into 2-way audio mode.

3. The channel will perform a Hook Flash with the time value

as programmed in Option 111/211 and then start to dial the

digits programmed.

Options 1A8/2A8 - 1AF/2AF must be programmed in the following manner: Digits 1-9 are programmed as the numbers 1-9. The digit “A” must be pro-

grammed if a zero is needed anywhere in the dial string as the digit zero is used to indicate to the line card that there are no more digits to dial. If a '*' is
