7.0 SG-DRL5/DRL5E/DRL5-2L PSTN Line Cards
- 127 -
DTMF Digit Sent DTMF Digit Received DTMF Digit Sent DTMF Digit Received
9 9 9 9
A 0 A 0
B * B *
C C C C
D 3 second pause D 3 second pause
E E E E
F F F F
For example: to have the receiver transfer a 2-way audio call to Ext. 51386, with a 3 second pause between the transfer command and dialing, Options
1A8/2A8 to 1AF/2AF would be programmed as the following:
A8 = B7 AC = 60
A9 = AD AD = 00
AA = 51 AE = 00
AB = 38 AF = 00
SG-DRL5 Option 1B0/2B0: CCITT Audio Format Enable bits
Default (00)
This option is similar to Option 17F/27F. It gives you the ability to enable and disable audio for the selected CCITT formats. A '1' in the formats bit pos-
ition will enable the format for audio. A '0' in the formats bit position will disable audio for the format.
Bit 0 Robofon FormatBit 4 Not Used
Bit 1 VONK FormatBit 5 Outel format
Bit 2 Stratel FormatBit 6 Not used
Bit 3 CESA FormatBit 7 Not used
For example, if the user wants audio to work only for Robofon format, Option 1B0/2B0 should be programmed as 11 HEX which enables bit 0 and bit
4.
SG-DRL5 Option 1B1/2B1: DMP Area BIN or DEC Option
Default (00)
This option is similar to the DMP receiver.
00 = Area is sent to the automation in BINARY
01 = Area is sent to the automation in DECIMAL
The printer outputs remain unchanged.
Examples: Area is sent to the linecard as C0,
BINARY setting
Automation:
P01001 20999 L0480TIMAREA 1
P01001 20999 L0440TIMAREA 2
Printer:
00-01-001-20999--Close USR:04 AREA1 TIMAREA 1
00-01-001-20999--Close USR:04 AREA2 TIMAREA 2
DECIMAL setting
Automation:
P01001 20999 L0401TIMAREA 1
P01001 20999 L0402TIMAREA 2
Printer:
00-01-001-20999--Close USR:04 AREA1 TIMAREA 1
00-01-001-20999--Close USR:04 AREA2 TIMAREA 2
