7.0 SG-DRL5/DRL5E/DRL5-2L PSTN Line Cards
- 128 -
SG-DRL5 Option 1B2/2B2: DTMF Format Disable #1
Default (00)
This option is bit oriented and will disable the decoding of the following DTMF formats.
Bit Description Example formats
0 15 digits DTMF format Scantronics 6-8-1
1 13 digits DTMF format Scantronics 4-8-1, Ademco Highspeed 4
2 8 digits DTMF format Sur-Gard 4-3 with checksum, 4-3-1 FBI Superfast, Ademco 4-1 express
3 22 digits DTMF format Contact ID 10 digit
4 11 digits DTMF format Acron 3, Ademco Highspeed 2, Scantronics 2-8-1
5 12 digits DTMF format Acron 4, Ademco Highspeed 3, Scantronics 3-8-1
6 23 digits DTMF format Scantronics 6-16-1
7 14 digits DTMF format Scantronics 4-8-1 with checksum, Scantronics 5-8-1
SG-DRL5 Option 1B4/2B4: 4/3 DTMF format type
Default (00)
When disabled this option will allow the receiver to receive 4/3 DTMF formats as Sur-Gard 4/3. When enabled the receiver will be able to receive 4/3
TMF as a 4/2/Checksum format.
SG-DRL5 Option 1B5/2B5: FSK Format disable
Default (00)
This option is bit oriented and will disable the decoding of the following pulse formats:
Bit enabled
--------------------------
0x01: Varitech Disable
0x02: Silent Knight Disable
0x04: BFSK Disable
0x08: - 0x80: Not used
SG-DRL5 Option 1B6/2B6: 4-2 Conversion to Ademco High Speed
Default (00)
When a 4-2 format message is received on the receiver, the computer and printer messages will normally be outputted in the standard 4-2 format (Option
1B6/2B6 set to 0). However, when this option is enabled (set to 01) the standard 4-2 opening and closing codes by users (B0 - BF and C0 - CF) will be
translated to Ademco High Speed. Whenever a 4-2 code beginning with B is received, an opening report is sent and whenever a 4-2 code beginning
with a C is received a closing report is sent. The User Identifier will be set to match the zone identifier of the message.
The 4-2 format signal: ACCT XY will be converted to the Ademco High Speed format signal:
If X is B (Opening) the signal will be:ACCT Y222 2222 2
If X is C (Closing) the signal will be: ACCT Y444 4444 4
Example:
If the 4-2 opening event is:1234 B1
The translated Ademco High Speed is:1234 1222 2222 2
If the 4-2 closing event is:1234 CB
The translated Ademco High Speed is:1234 B444 4444 4
The following table outlines all possible translation into Ademco High Speed for the transmission of the standard 4-2 opening and closing codes:
(Please note that account number 1234 was used for example purposes).
4-2 Format signal Automation output Printer output
1234 B1 101001 1234 1222 2222 2 01-001 1234 1222 2222 2
1234 B2 101001 1234 2222 2222 2 01-001 1234 2222 2222 2
