7.0 SG-DRL5/DRL5E/DRL5-2L PSTN Line Cards

- 129 -

4-2 Format signal Automation output Printer output

1234 B3 101001 1234 3222 2222 2 01-001 1234 3222 2222 2

1234 B4 101001 1234 4222 2222 2 01-001 1234 4222 2222 2

1234 B5 101001 1234 5222 2222 2 01-001 1234 5222 2222 2

1234 B6 101001 1234 6222 2222 2 01-001 1234 6222 2222 2

1234 B7 101001 1234 7222 2222 2 01-001 1234 7222 2222 2

1234 B8 101001 1234 8222 2222 2 01-001 1234 8222 2222 2

1234 B9 101001 1234 9222 2222 2 01-001 1234 9222 2222 2

1234 BA 101001 1234 0222 2222 2 01-001 1234 0222 2222 2

1234 BB 101001 1234 B222 2222 2 01-001 1234 B222 2222 2

1234 BC 101001 1234 C222 2222 2 01-001 1234 C222 2222 2

1234 BD 101001 1234 D222 2222 2 01-001 1234 D222 2222 2

1234 BE 101001 1234 E222 2222 2 01-001 1234 E222 2222 2

1234 BF 101001 1234 F222 2222 2 01-001 1234 F222 2222 2

1234 C1 101001 1234 1444 4444 4 01-001 1234 1444 4444 4

1234 C2 101001 1234 2444 4444 4 01-001 1234 2444 4444 4

1234 C3 101001 1234 3444 4444 4 01-001 1234 3444 4444 4

1234 C4 101001 1234 4444 4444 4 01-001 1234 4444 4444 4

1234 C5 101001 1234 5444 4444 4 01-001 1234 5444 4444 4

1234 C6 101001 1234 6444 4444 4 01-001 1234 6444 4444 4

1234 C7 101001 1234 7444 4444 4 01-001 1234 7444 4444 4

1234 C8 101001 1234 8444 4444 4 01-001 1234 8444 4444 4

1234 C9 101001 1234 9444 4444 4 01-001 1234 9444 4444 4

1234 CA 101001 1234 0444 4444 4 01-001 1234 0444 4444 4

1234 CB 101001 1234 B444 4444 4 01-001 1234 B444 4444 4

1234 CC 101001 1234 C444 4444 4 01-001 1234 C444 4444 4

1234 CD 101001 1234 D444 4444 4 01-001 1234 D444 4444 4

1234 CE 101001 1234 E444 4444 4 01-001 1234 E444 4444 4

1234 CF 101001 1234 F444 4444 4 01-001 1234 F444 4444 4

SG-DRL5 Option 1B8/2B8: DTMF Format Disable#2

Default (00)

This option is bit oriented and will disable the decoding of the following DTMF formats:

Bit enabled

0x01 9 digits DTMF format

0x02 Not used

0x04 Not used
