17. Electrical System
17-16
Headlight bulb replacement
Hold the headlight bulb socket.
Rotate the headlight bulb and remove it.
Replace with new bulb if necessary.
Specification:
Lo-beam bulb 12V 55W (H11)
Hi-beam bulb 12V 55W (H11)
Caution
z Headlight bulb can be replaced without
removing the front cover.
z Never touch the bulb with bare fingers, which
may create a heat point and lead to premature
bulb failure.
z Clean the fingerprint left on the bulb with
alcohol.
Installation
Install the bulb of the headlight in reverse order of
removal.
Front winker bulb replacement
Hold the winker bulb socket.
Rotate the winker bulb and remove it.
Replace with new bulb if necessary.
Specification:
Winker light bulb 12V 21W
Installation
Install the bulb of the headlight in reverse order of
removal.
