Symmetricom 5071A User Manual

Chapter 5 Command Reference
Rear-Panel Status Output Operation
104 Operating and Programming Manual
3. By adding all the false condition bit values (in this case, only one) we get the
value 1024 which is used to program the STAT:OPER:NTR command.
The resulting SCPI command entries are:
• STAT:OPER:ENAB 7937
• STAT:OPER:PTR 6913
• STAT:OPER:NTR 1024
You may, at any time set the rise and clear the fall registers of the OPERation
and QUEStionable subsystems by issuing the STATus:PRESet command.
Although these examples used the OPERation register functions, you can also
use the QUEStionable register functions that are available for questionable
conditions as well.
NOTE
