2. General Description
32 Instructions for Use for infinite® 200 No. 30017581 Rev. No. 1.4 2008-07
Washing (hardware buttons):
Washing can also be performed without using the software. Washing parameters
can be stored on the injector by clicking Save as Default on the Wash tab of the
Injector Maintenance dialog box (in the Settings menu, click Injectors... and the
Injector Maintenance dialog box appears) of the i-Control software. Press the
Prime/Wash button on the injector box to start the washing sequence using the
default parameters. (see Figure 2-4: Injector-box with injector in ‘service position’,
page 24). The injector must be connected the inst
rument and the instrument must
be switched on. Start the wash procedure by pressing and holding the
Prime/Wash button for more than 3 seconds.
STOP
Caution
The injector carrier must be in the service position
for the action ‘wash’.
Do not perform washing when the injector is in the instrument!
STOP
Important
Be sure to run a final wash procedure with distilled water and empty the
injector system. For good care and lifetime fill the injector system with
liquid (water) before turning off the instrument.
STOP
Important
Please see the corresponding reagent kit for advice on how to remove
the substrate completely from the tubing system.
STOP
Important
Take good care of the injectors, because if they are damaged the
accuracy of dispensing may be affected. This can result in damage to
the instrument.
Note:
Injector needles can be replaced by exchanging the injector carrier
together with the corresponding tubing.
STOP
Important
The button(s) on the injector box include two functions:
• Press the button for less than 3 seconds to start PRIME.
• Press the button for more than 3 seconds to start WASH.
The parameters have to be set in the i-Control software.
