You can proceed to remove the plate:

Remove the right side casing (L).

Loosen the nut. (TOOL: 6mm hexa-

gon key wrench and 19mm open end

wrench)

TECHNOGYM BIKE LIVE Technical Service Guide

Rev. 2.0

- 71 -TSG-00187-EN - Uncontrolled copy if printed
