Remove the two screws to disassem-
ble the support casing of display plate,
(TOOL: 2,5 mm hexagon key wrench).
Remove the four screws to disassem-
ble the display plate, (TOOL: 2,5 mm
hexagon key wrench).
TECHNOGYM BIKE LIVE Technical Service Guide
Rev. 2.0
- 80 - TSG-00187-EN - Uncontrolled copy if printed
