ATTENTION: NOTE THE COR-

RECT ORIENTATION OF THE

TWO SPRING WASHERS.

Before reassembly procedure, clean

the frame pin from grease residual.

TECHNOGYM BIKE LIVE Technical Service Guide

Rev. 2.0

- 86 - TSG-00187-EN - Uncontrolled copy if printed
