RUN XT: Service & Maintenance Manual - rev. 2.0
Page 7.16
To reassemble the DRIVEN ROLLER, the
DRIVING ROLLER, the TREAD BELT and the
MOTOR BELT, carry out the above steps in
reverse order.
To ensure correct reassembly, insert the
DRIVING ROLLER in the MOTOR
BELT before assembling it on the
supports.
After completing this procedure, adjust
the tension and centering of the TREAD
BELT as described in paragraphs 8.1.
8.2. 8.3. and adjust the tension and
alignment of the MOTOR BELT as
described in paragraph 8.4.
