SELECTION LINE: Service & Maintenance Manual - rev. 4.0
Page 3.57
4. Place the bench on the floor.
5. Remove the nylon bag wrapper from the two
parts, being careful not to lose the three
assembly screws included in the packing.
6. Use an 8-mm Allen wrench to lock down the
two screws c shown in Photo 3.3-40, which
fix the upper part of the leg rest rollers.
7. Use a 5-mm Allen wrench to lock down the
screw d shown in Photo 3.3-40, which fixes
the lower part of the leg rest rollers, as
indicated by the arrow.
