Tektronix DPO4000 Series User Manual

Display Waveform Data
Scaling and Positioning a Waveform
Use the h orizontal controls to adjust the time base, adjust the trigger point, and to examine w aveform details more closely.
Original waveform Scaled horizontally Positioned horizontally
120 DPO4000 Series User Manual
