Installation
Quick Tips
Use the shortest possible ground lead and signal
path to minimize probe-induced ringing and
distortion on the measured signal.
Short ground lead
Long ground lead
Installing an Application Module
CAUTION. To avoid damage to the oscilloscope or application mod ule, observe ESD precautions. (See page 11, Powering
On the Oscilloscope.)
Turn off the oscilloscope power while removing or adding an application module.
(See page 14, Powering Off th e Oscilloscope.)
