Tektronix DPO4000 Series User Manual

Installation
2. Check the shape of the displayed
waveform to determine if your probe is
properly compensated .
Properly compensated
Under compensated Over compensated
3. If necessary, adjust your probe. Repeat
as needed.
18 DPO4000 Series User Manual
