Use Application Modules
Use Application Modules
Optional application module packages extend the capability of your oscilloscope. Install up to four application modules at one
time. Application modules go into the two slots with windows in the upper right corner of the front panel. Two additional slots
are directly behind the two that you can see.
Refer to the DPO4000 Series Application Module Installation Instructions that came with your application module for instructions
on installing and testing an application mod ule. Some modules are described below. Additional packages may be available.
Contact your Tektronix representative or visit our Web site at www.tektron ix.com for more informa tion. Also, refer to Contacting
Tektronix at the beginning o f the manual.
The DPO4EMBD Serial Tr iggering and Analysis Module adds triggering on packet level information in serial bu ses used in
embedded designs (I
2
C and SPI), as well as analytical tools to help you efficiently analyze your se rial bus. These include digital
views of the signal, bus views, packet decoding, search tools, and event t ables with timestamp information.
The DPO4AUTO Se rial Triggering and Analysis Module adds triggering on packet level information in serial buses used in
automotive designs (CAN), as well as analytical tools to help you efficien tly analyze your serial bus. These include digita l views
of the signal, bus views, pa cke t decoding, search tools, and event tables with timestamp information.
200 DPO4000 Series User Manual
