Preface
Preface
This manual describes the installation and operation of the following DPO4000 Series Instruments:
DPO4104 DPO4054 DPO4034 DPO4032
Key Features
DPO4000 Series instruments can he lp you verify, debug, and characterize electronic designs. Key features include:
1 GHz, 500 MHz, and 350 MHz bandwidths
2 a nd 4 channel models
Sample ra tes up to 5 GS/s on all channels
10 Megapo int record length on all channels
I
2
C, SPI, and CAN serial triggering and a nalysis
(Requires use of the DPO4EMBD (for I
2
C and SPI) or DPO4AUTO (for CAN) application modules)
Wave Inspector controls for managing long record lengths, with zoom and pan, play and pause, search and mark
10.4 inch (264 mm) X GA color display
Small footprint and lightweight, at 140 mm (5.5 inches) deep and 5 kg (11 pounds)
USB and CompactFlash available for quick and easy storage
Built-in Ethernet port
USB 2.0 device port for direct PC control of the oscilloscope using USBTMC protocol
x DPO4000 Series U ser Manual
