Display Waveform Data
Setting Input Parameters
Use the vertical controls to select waveforms, adjust the waveform vertical position and scale, and set input parameters.
1. Push channel button 1, 2, 3,or4 to bring up
the vertical menu for the designated waveform.
The vertica l menu only affects the selected
waveform.
Pushing a channel button will also select or
cancel that waveform selection.
2. Push Co upling.
Coupling
DC
Invert
Off
Bandwidth
Full
Fine Scale
100mV/div
Offset
0.00V
Position
0.00 div
Probe
Setup
1X
122 DPO4000 Series User Manual
