Tektronix DPO4000 Series User Manual

Display Waveform Data
Quick Tips
Variable persistence accumulates record points for a specified time interval. Each record point decays independently according
to the time interval. Use variable persistence for displaying infrequently appearing signal anomalies, such as glitches.
Infinite persistence continuously accumulates record points until you change one of the acquisition display settings. Use infinite
persistence for d isplayin g unique signal anomalies, such as glitches.
Setting Waveform and Graticule Intensity
1. Push the front-panel Intensity button.
This will bring up the intensity readout on the
display.
DPO4000 Series User Manual 115
