Tektronix DPO4000 Series - Choosing a Trigger

Trigger Setup and Run
Choosing a Trigger
To select a trigger:
1. Push Trigger Menu.
Edge
Pulse
Width
Runt
Logic
Setup &
Hold
Rise/Fall
Time
Video
2. Push Type repeatedly to select the trigger
type to use.
NOTE. The bus trigger require s use of the
DPO4EMBD or the DPO4AUTO application
module.
Bus
