Analyze Waveform Data
The vertical cursor lines on the display measure
horizontal parameters, typically time.
Using Math Waveforms
Create math waveforms to support the analysis of your channel and reference waveforms. By combining and transforming source
waveforms and other data into math w aveforms, you can derive the data view that your application requires.
Use the following procedure for executing simple (+, –, *, ÷) math operations on two waveforms:
1. Push Math .
150 DPO4000 Series User Manual
