Analyze Waveform Data
2. Push Dual Wfm Math.
Dual Wfm
Math
FFT Advanced
Math
3. On the side-bezel menu, set the sources
to either channel 1, 2, 3, 4, or reference
waveforms R1, 2, 3,or4. Choose the +, –,
x,or÷ operators.
4. For example, you might calculate power by
multiplying a voltage waveform and a current
waveform.
DPO4000 Series User Manual 151
