Acquire the Signal
Changing the Acquisition Mode and Record Length
Use this procedure to change the acquisition mode.
1. Push Acquire.
2. Push M ode.
Mode
Average
Record
Length
10k
Reset
Horizontal
Position
Waveform
Display
80 DPO4000 Series User Manual
