Tektronix DPO4000 Series User Manual

Acquire the Signal
Acquisition
Mode
Sample
Peak
Detect
Hi Res
Envelope
3. Then choose the acquisition mode from
the side-bezel menu. You can chose from:
Sample, Peak Detect, H i Res, Envelope, or
Average.
NOTE. Peak Detect and High Res require more
than one sample point per sample interval. If there
is only one sample p oint, these two modes will
appear the same as sample mode.
Average
16
DPO4000 Series User Manual 81
