Tektronix DPO4000 Series User Manual

Analyze Waveform Data
Amplitude Measurements (cont.)
Measurement Description
Mean
The arithmetic mean over the entire w aveform or gated region.
Cycle Mean The arithmetic m ean over the first cycle in the waveform or the first cycle in the gated region.
RMS The true Root M ea n Square voltage over the entire waveform or gat ed region.
Cycle RMS The true Ro ot Mean Square voltage over the first cycle in the waveform or the first cycle
in the gated region.
DPO4000 Series User Manual 135
