Save and Recall Information
4. If you are saving information to a CompactFlash
or USB memory device, turn multipurpose
knob a to scroll through the file structure.
D: is the CompactFlash drive.
E: is the USB drive plugged into the USB
port on the front of the oscilloscope.
F: and G: are the USB drives plugged
into the USB ports on the rear of the
oscilloscope.
Push Select to open or close file folders.
Push the Menu Off button to cancel the save
operation, or push a side-b ezel menu Save to
Selected File item to complete the operation.
186 DPO4000 Series User Manual
