Get Acquainted with the Instrument
1. The acquisition readout shows when an
acquisition is running, sto pped, or when
acquisition preview is in effect. Icons are:
Run: Acq uisitions en abled
Stop: Acquisitions not enabled
Roll: In roll mode (40 m s/div or slower)
PreVu: In this state, the oscilloscope
is stopped or between triggers. You
can change the horizontal or vertical
position or scale to see approximat ely
what the next acquisition will look like.
RUN
60 DPO4000 Series User Manual
