Menus
SPG INPUT TRIGG
ER. Select this menu item a nd press the left (◄)orright
(►) arrow b utton to enable or d isable the SPG Input Trigger function. Press
the ENTER button to implement the selection. When enabled, the SPG Input
Trigger function allows a Tektronix SPG8000 generator to trigger a changeover if
it detects an error condition, such as the loss of genlock. (See page 31, Configure
the SPG trigger input.)
EXPANSION PORT. Select this menu item and press the left (◄)orright(►)
arrow button to enable or disable the Expansion Port. Press the ENTER button
to implement the selection. When enab led, you can connect multiple ECO8000
Series instruments together to act as a single changeover unit. (See page 35,
Configure the Expansion port.)
STARTUP DELAY. Select this menu item and press the left (◄)orright(►) arrow
button to adjust the startup delay. You can adjust the delay between 0 and 300
seconds in 5 second increments. (See page 30, Configure the startup delay.)
PREFERRED SUPPLY. Select this menu item and press the left (◄)orright(►)
arrow
button to select which of the two installed Power Supply modules will be
the preferred (active) supply. This menu selection applies only when Option
DPW is installed. (See page 37, Configuring the preferred (active) s upply (Option
DPW only).)
NETWORK CONFIG. Select this menu item and press the ENTER button to access
the
NETWORK CONFIG submenu, which you can use to configure the network
settings or to view the MAC address of the instrument. (See page 72, NETWORK
CONFIG submenu.)
WEB USER INTERFACE. Select this menu item and press the left (◄)orright
(►) arrow button to select the level of instrument control that can be exercised
b
y a Web browser connecting to the instrument. (See page 95, How to use the
Web Interface.) The following settings are available:
Full Control. This setting allows the a user to have full control of instrument
settings from a Web browser.
Read Only. This setting allows the a user to have read-only acc ess to
instrument settings from a Web browser.
Disable. This setting disables a Web browser from c onnecting to the
instrument.
SNMP CONFIG. Select this menu item and press the ENTER button to access
the SNMP CONFIG submenu, which you can use to configure the SNMP trap
addresses, to configure the public and private community strings, and to configure
which events will trigger an SNMP trap to be sent from the instrument. (See
page 74, SNMP CONFIG submenu.)
68 ECO8000 Series Automatic Changeover Unit User Manual
