Application Examples
This section presents a series of application examples. These simplified examples
highlight the features of the oscilloscope and give you ideas for using it to solve
your o wn test problems.
Taking simple measurements
Using A utoset
Using the Measure Menu to take automatic measurements
Measuring
two signals and calculating gain
Using Autorange to examine a series o f test points
Taking cursor measurements
Measuring ring frequency and ring amplitude
Measuring pulse width
Measuring rise time
Analyz
ing signal detail
Looking at a noisy signal
Using the average function to separate a signal from noise
Capturing a single-shot signal
Optimizing the acquisition
Measuring propagation delay
Tri
ggering on a pulse width
Triggering on a video signal
Triggering on video fields and video lines
Using the window function to see waveform details
Analyzing a differential communication signal u sing Math functions
Viewing impedance changes in a network using XY mode and persistence
Data logging (non-EDU models only)
Limit testing (non-EDU models only)
TBS1000B and TBS1000B-EDU Series Oscilloscopes User Manual 25
