Reference
Help
Push the He lp button to display the Help menu. The topics cover all the menu
options and controls of the oscilloscope.
Horizontal
You can u se the
horizontal controls to adjust the trigger point location relative to
the acquired waveform and to adjust the horizontal scale (time/division).
A readout near the top right of the screen displays the current horizontal position
in seconds. The oscilloscope also indicates horizontal position with an arrow
icon at the top of the g raticule.
Knobs and Buttons
Horizontal Position Knob. Use to control the position of the trigger relative to
the center of the screen.
The trigger point can be set to the left or the right of the center of the screen. The
maximum number of divisions to the left depends on the Horizontal Scale (ti
me
base) setting. For most scales, the maximum is at least 100 divisions. Placing the
trigger point off the screen to the left is called Delayed Sweep.
Push to center the trigger on the screen.
Horizontal Scale Knob (seconds/division). Use to change the horizontal time scale
to magnify or compress the waveform.
Key Points
Horizontal Scale. If waveform acquisition is stopped (using the Run/Stop
or Single button), the Horizontal Scale control expands or compresses the
waveform. Use to zoom in on a detail of the waveform.
Scan Mode Display (Roll Mode). When the Horizontal Scale control i s set to
100 ms/div or slower and the trigger mode is set to Auto, the oscilloscope enters
the Scan acquisition mode. In this mode, the waveform display updates from left
to right. There is no trigger o r horizontal position control of waveforms during
scan mode. (See page 71, Scan Mode Display.)
Math
Push the Math (M) button to display waveform math operations. Push the Math
button again to remove math waveforms. (See page 106, Vertical Controls.)
Options Comments
Operation: +, -, ×
Math operations; s ee the next table
Sources Sources used for the operations; see the next table
TBS1000B and TBS1000B-EDU Series Oscilloscopes User Manual 85
