Appendix A: Specifications
You can find a more complete list of TBS1000B and TBS1000B-EDU product
specifications in the TBS1000B and TBS1000B-EDU Series Oscilloscopes
Service Manu
al.
Oscilloscope Specifications
Table 1: Mo
del overview
TBS1052B/EDU TBS1072B/EDU TBS1102B/EDU TBS115 2B/EDU TBS1202B/EDU
Bandwidth 50 MHz 70 MHz 100 MHz 150 MHz 200 MHz
Channels
22222
Sample rate of each channel 1.0 GS/s 1.0 GS/s 2.0 GS/s 2.0 GS/s 2.0 GS/s
Record length 2.5k points at all time bases
Table 2:
Vertical system — Analog channels
Characteristic Description
Vertical resolution 8 bits
Input sensitivity range
2 mV to 5 V/div on all models with calibrated fine adjustment
DC gain accuracy ±3% from 10 mV/div to 5 V/div
Maximum input voltage
300 V
RMS
CAT II; derated at 20 dB/decade above 100 kHz to 13 V
pp
AC at 3 MHz
Offset range 2 mV to 200 mV/div; at 1.8 V
>200 mV to 5 V/div; ±45 V
Bandwidth limit 20 MHz
Input coupling
AC, DC, Ground
Input impedance
1MΩ in parallel with 20 pF
Vertical zoom
Vertically expand or compress a live or stopped waveform
Table 3: Horizontal system — Analog channels
Characteristic Description
Time base range
5nsto50s/div
Time base accuracy 50 ppm
Horizontal zoom
Horizontally expand or compress a live or stopped waveform
Table 4: Input/Output ports
Characteristic Description
USB interface USB host port on the front panel supports USB flash drives.
USB device port on the back of the instrument supports connection to a PC.
GPIB interface Optional
