Reference
Option Settings Comments
Enters the hig
hlighted alphanumeric character at the
current Name field cursor position
A - Z, 0 - 9, _,
.
Use the multip
urpose knob to select an alphanumeric
character or the Backspace, Delete Character, or Clear
Name functions
Backspace
Changes the menu button 1 option to the Backspace
function. D
eletes the character to the left of the
highlighted character in the Name field
Delete
Character
Changes the menu button 1 option to the Delete
Character function. Deletes the highlighted character
from the Na
me field
Enter
Character
Clear Nam
e
Changes t
he menu button 1 option to Clear Name.
Deletes all characters from the Name field
Vertica
l Controls
You can use the vertical controls to display and remove waveforms, adjust vertical
scale and position, set input parameters, and for vertical math operations. (See
page 85, M
ath.)
Channel Vertical Menus
There is a separate vertical menu for each channel. Each option is set individually
for each channel.
Options Settings C omments
Coupling DC, AC, Ground DC passes both AC and DC components of the
input signal
AC blocks the DC component of the input signal
and attenuates signals below 10 Hz
Ground disconnects the input signal
Options Settings Comments
BW Limit
20 MHz
1
,Off
Limits the bandwidth to reduce display noise;
filters the signal to reduce noise and other
unwanted high frequency components
Volts/Div Coarse, Fine Selects the resolution of the Scale (Volts/Div)
knob
Coarse defines a 1-2-5 sequence. Fine
changes the resolution to small steps
between the coarse settings
106 TBS1000B and TBS1000B-EDU Series Oscilloscopes User Manual
