Reference

Options Comments

Position

Use the multipurpose knob to set the vertical position of the

resultant Math waveform

Vertical Scale Use the multipurpose knob to set the vertical scale of the

resultant Ma

th waveform

The Math Menu includes Sources options for each operation.

Operation Sources option Comments

+ (addition) Ch1 + Ch2 Channels 1 and 2 are added

together

Ch1 - Ch2 The channel 2 waveform is

subtracted from the channel 1

waveform

- (subtraction)

Ch2 - Ch1 The channel 1 waveform is

subtracted from the channel 2

waveform

× ( multiplication) Ch1 × Ch2 Channels 1 and 2 are multiplied

together

Key Points

Waveform Units. The combination of source waveform units determine the

resulting units for the Math waveform.

Waveform unit Waveform unit Operation Resulting Math unit

+or-

Measure

Push the Measure button to a ccess a utoma tic measurements. There are 34 types

of measurements available. You c an display up to six at a time. The oscilloscope

displays the measurements towards the bottom of the screen after you choose

them.

Key Points

Taking Measurements. You can display up to six automatic measurements at a

time. The waveform channel must be on (displayed) to make a measurement.

Automated measurements c annot be taken on reference waveforms, or while

using XY or scan mode. The measurements update about two times per second.

86 TBS1000B and TBS1000B-EDU Series Oscilloscopes User Manual
