Reference
Menu Off
Push Menu Off to clear displaye d menus from the screen.
Print-Ready
Screenshots
You can set up the oscilloscope to save print-ready images through the Utility
► - more - page 1 of 2 (page 1 of 3 on EDU models) ►Options ► Printer
Setup menu
.
Option Setting Comments
Ink Saver On, Off
Prints the screen image on a
white background when you
select On
Layout
1
Portrait, Landscape Printer output orientation
File Format Bmp, Jpg
Print file format
1
The printer may override your selection for best fit.
Reference Menu
The Reference menu can t urn on or turn off reference memory waveforms
from the display. The waveforms are stored in the non-volatile memory of the
oscilloscope, and h ave the following designations: RefA and RefB.
To display (recall) or hide a reference waveform, follow these steps:
1. Push the Ref front panel button.
2. Pus
h the side-menu button corresponding to the reference waveform you
wish to display or hide.
Ref
erence waveforms have the following characteristics:
Reference waveforms are displayed in white
Two reference waveforms can be displayed a t the same time
Vertical and horizontal scale readouts display at the bottom of the screen
Reference waveforms cannot be zoomed or panned
You can display one or two reference waveforms at the same time as "live"
channel waveforms. If you display two reference waveforms, you must hide one
waveform before you c an display a different one.
Refer to Save Waveform for information on how to save reference waveforms.
(See page 94, Save Waveform.)
TBS1000B and TBS1000B-EDU Series Oscilloscopes User Manual 91
