Tektronix TB1052B-EDU User Manual

Reference
Save/Recall
Push the Save/Recall button to save oscilloscope setups, screen images, or
waveforms, or to recall oscilloscope setups or waveforms.
The Save/Recall menu is made up of many submenus which you can access
through an Action option. Each Action option displays a menu that allows you to
further defi
ne the save or recall function.
Action o ption s Comments
Save All Contains the option that configures the Print button to send data to a
printer o
rtosavedatatoaUSBflash drive
Save Imag
e
Saves a sc
reen image to a fileinaspecified format
Save Set
up
Saves th
e current oscilloscope settings to a fileinaspecified folder
or in nonvolatile setup memory
Save Waveform Saves the specified waveform to a file or to reference memory
Recall Setup Recalls an oscilloscope setup file from a USB flash drive or from a
location in nonvolatile setup memory
Recall Waveform Recalls a wa veform file from a USB flash drive to reference memory
Save All
The Save All action configures the Print b utton to save data to a USB flash drive,
or to send data to a printer.
Options Settings or submenus Comments
Saves All to Files (See page 63.)
Saves Image to File (See page 64.)
Print Button
Prints
Lists the contents of the current USB
flash drive folder
Change Folder
New Folder
(See page 60, File Management
Conventions.) (S ee page 105, File
Utilities for the USB Flash Dri ve .)
Select Folder
Back
Returns to the Save All menu
About Save All
Displays the help topic
Save Image
The Save Image action saves a screen image to a file in a specified format.
Options Settings or submenus Comments
File Format
BMP, JPEG Sets the screen image graphics file
format
About Saving
Images
Displays the help topic
92 TBS1000B and TBS1000B-EDU Series Oscilloscopes User Manual
